Features

• Made from 6/4 titanium
• Compatible with either 24T or 48T engagement systems
• Freehub bodies come with:
  • 2 bearings installed
  • 3 pawl springs
  • Pawls not included
    • Use your old pawls unless damaged
• 1.8mm cassette spacer included on XD/XDR drivers only
  • Spacers available separately for Shimano HG 11 and HG 10
• Not compatible with other brands of hubs

Specs for “current” freehub bodies

• Shimano/SRAM 11 speed HG
  • If you are swapping from a Shimano Micro Spline driver, you will need to purchase the correct axle kit for the new driver (see Hub Parts>Axle Kits)
  • Fits Shimano/SRAM 8/9/10/11 speed HG cassettes
  • Fits new Shimano road 12 speed Hyperglide+ Ultegra and Dura-Ace cassettes
  • Fits SRAM Eagle 12 speed PG-1230 cassette
  • Purchase a 1.8mm cassette spacer for use with 8/9/10 and 11 speed mountain cassettes
    • 11 speed Shimano road cassettes do not need a spacer (except Ultegra HG-800 11/34)
  • Bearings: 1x 6902 and 1x 3802W
• SRAM XD/XDR
  • If you are swapping from a Shimano Micro Spline driver, you will need to purchase the correct axle kit for the new driver (see Hub Parts>Axle Kits)
  • Fits SRAM XD mountain and XDR road cassettes
  • Comes with 1.8mm spacer for use with XD mountain cassettes
  • Bearings: 2x 3802W
• Shimano Micro Spline
  • If you are swapping to a Micro Spline driver, you will need to purchase the correct axle kit for the new driver (see Hub Parts>Axle Kits)
  • Fits Shimano Micro Spline cassettes
  • If you are simply replacing a Micro Spline freehub body, you already have the correct axle
  • Bearings: 2x 3802W
• Campy 11 speed
  • If you are swapping from a Shimano Micro Spline driver, you will need to purchase the correct axle kit for the new driver (see Hub Parts>Axle Kits)
  • Fits 9/10/11/12 speed Campy cassettes
  • Bearings: 2x 3802W
• Campy N3W/EKAR 13 speed
  • If you are swapping from a Shimano Micro Spline driver, you will need to purchase the correct axle kit for the new driver (see Hub Parts>Axle Kits)
  • Fits Campy N3W/EKAR 13 speed cassettes
  • Will fit Campy 10/11/12 speed cassettes with Campy adapter/part #AC21-N3W
  • Bearings: 2x 3802W
  • Comes with a 2.5mm spacer that goes between the drive side axle end and the outer bearing of the driver
